{"Failure Rate":"Not Required","Military Standard":"Not Required","Lead Style":"Radial","Lead Spacing":"11.44(mm)","Product Height (mm)":"34.29(mm)","Rad Hardened":"No","DC Current":"5000(mA)","Operating Temp Range":"-40C to 130C","Product Depth (mm)":"15.37(mm)","Product Diameter (mm)":"Not Required(mm)","Technology":"Toroid","Inductance":"50(uH)","Impedance":"Not Required(ohm)","Tolerance (+ or -)":"20%","Type":"Power","Product Length (mm)":"24.26(mm)","DC Resistance":"0.05(TYP)(ohm)"}...

{"Failure Rate":"Not Required","Packaging ":"Tube","Number of Terminals":"4","Military Standard":"Not Required","Technology":"Toroid","Product Height (mm)":"12.7(mm)","Rad Hardened":"No","DC Current":"5000(mA)","Operating Temp Range":"-40C to 130C","Product Depth (mm)":"25.4(mm)","Product Diameter (mm)":"Not Required(mm)","Inductance":"52(uH)","Impedance":"Not Required(ohm)","Tolerance (+ or -)":"20%","Type":"Power","Product Length (mm)":"30.99(mm)","DC Resistance":"0.025(TYP)(ohm)"}...

{"Failure Rate":"Not Required","Packaging ":"Tape and Reel","Military Standard":"Not Required","Technology":"Wirewound","Product Height (mm)":"12.7 mm","Rad Hardened":"No","DC Current":"5000 mA","Operating Temp Range":"-40C to 130C","Product Depth (mm)":"25.4 mm","Product Diameter (mm)":"Not Required mm","Inductance":"52 uH","Impedance":"Not Required ohm","Tolerance (+ or -)":"20%","Type":"Power","Product Length (mm)":"30.99 mm","DC Resistance":"0.025 ohm"}...

{"Status":"ACTIVE","Terminal Finish":"NOT SPECIFIED","Mfr Package Description":"RADIAL LEADED","Operating Temperature-Min":"-40 Cel","Terminal Placement":"RADIAL","Tolerance":"20 %","Number of Terminals":"2","Operating Temperature-Max":"130 Cel","Rated Current-Max":"5 A","Terminal Shape":"WIRE","Manufacturer Series":"KM","Number of Functions":"1","Inductor Type":"GENERAL PURPOSE INDUCTOR","Inductor Application":"POWER INDUCTOR","Inductance-Nom (L)":"50 uH","Special Feature":"SIMPLE SWITCHER","Shape/Size Des...

{"Category":"Inductors, Coils, Chokes","Current Rating":"5A","Catalog Drawings":"Thru-hole Klipmount Series_KM-4.0","Height - Seated (Max)":"1.350\" (34.29mm)","Operating Temperature":"-40\u00b0C ~ 130\u00b0C","Package / Case":"Radial","Current - Saturation":"-","Tolerance":"\u00b120%","Shielding":"Unshielded","DC Resistance (DCR)":"50 mOhm","Product Photos":"P0848NL","Type":"Toroidal","Datasheets":"P08_NL THT/SMT Pwr Switcher Inductors","Inductance":"50\u00b5H","Standard Package":"55","Size / Dimension":"0...

{"Status":"ACTIVE","Mfr Package Description":"RADIAL LEADED, ROHS COMPLIANT","Operating Temperature-Min":"-40 Cel","Terminal Placement":"RADIAL","Rated Current-Max":"5 A","Number of Terminals":"2","Operating Temperature-Max":"130 Cel","Terminal Shape":"WIRE","Manufacturer Series":"KLIPMOUNT","Number of Functions":"1","Inductor Type":"GENERAL PURPOSE INDUCTOR","Inductor Application":"POWER INDUCTOR","Inductance-Nom (L)":"50 uH","Tolerance":"20 %","Shape/Size Description":"CYLINDRICAL PACKAGE","DC Resistance"...

{"Category":"Inductors, Coils, Chokes","Current Rating":"5A","Operating Temperature":"-40\u00b0C ~ 130\u00b0C","Package / Case":"Nonstandard","Current - Saturation":"-","Type":"Toroidal","Shielding":"Unshielded","DC Resistance (DCR)":"25 mOhm","Height - Seated (Max)":"0.500\" (12.70mm)","Tolerance":"-","Datasheets":"P08 THT/SMT Toroid Simple Switcher","Inductance":"50\u00b5H","Standard Package":"15","PCN Obsolescence/ EOL":"Multiple Devices 02/Sep/2014","Frequency - Test":"-","Material - Core":"-","Size / D...

{"Category":"Inductors, Coils, Chokes","Current Rating":"5A","Catalog Drawings":"HCI-68 Big Foot Series","Height - Seated (Max)":"0.500\" (12.70mm)","Operating Temperature":"-40\u00b0C ~ 130\u00b0C","Package / Case":"Nonstandard","Current - Saturation":"-","Tolerance":"\u00b120%","Shielding":"Unshielded","DC Resistance (DCR)":"25 mOhm","Product Photos":"P0848SNL","Type":"Toroidal","Datasheets":"P08_NL THT/SMT Pwr Switcher Inductors","Inductance":"52\u00b5H","Standard Package":"15","Size / Dimension":"1.220\...

{"Category":"Inductors, Coils, Chokes","Current Rating":"5A","Operating Temperature":"-40\u00b0C ~ 130\u00b0C","Package / Case":"Nonstandard","Current - Saturation":"-","Type":"Toroidal","Shielding":"Unshielded","DC Resistance (DCR)":"25 mOhm","Height - Seated (Max)":"0.500\" (12.70mm)","Tolerance":"-","Datasheets":"P08_NL THT/SMT Pwr Switcher Inductors","Inductance":"50\u00b5H","Standard Package":"75","Size / Dimension":"1.220\" L x 1.000\" W (30.99mm x 25.40mm)","Frequency - Test":"-","Material - Core":"-...

{"Status":"ACTIVE","Terminal Finish":"NOT SPECIFIED","Mfr Package Description":"SMD","Operating Temperature-Min":"-40 Cel","Terminal Placement":"DUAL IN-LINE","Tolerance":"20 %","Number of Terminals":"4","Operating Temperature-Max":"130 Cel","Rated Current-Max":"5 A","Terminal Shape":"ONE SURFACE","Manufacturer Series":"BIGFOOT","Number of Functions":"2","Inductor Type":"GENERAL PURPOSE INDUCTOR","Inductor Application":"POWER INDUCTOR","Inductance-Nom (L)":"52 uH","Special Feature":"SERIES CONNECTED","Shape...

{"Status":"ACTIVE","Mfr Package Description":"RADIAL LEADED","Operating Temperature-Min":"-40 Cel","Terminal Placement":"RADIAL","Rated Current-Max":"5 A","Number of Terminals":"2","Operating Temperature-Max":"130 Cel","Terminal Shape":"WIRE","Manufacturer Series":"KLIPMOUNT","Number of Functions":"1","Inductor Type":"GENERAL PURPOSE INDUCTOR","Inductor Application":"POWER INDUCTOR","Inductance-Nom (L)":"50 uH","Tolerance":"20 %","Shape/Size Description":"CYLINDRICAL PACKAGE","DC Resistance":"0.0500 ohm"}...

{"SVHC:":"No SVHC (17-Dec-2014)","Inductance:":"50 \u00b5H","RMS Current (Irms):":"5 A","Inductance Tolerance:":"\u00b1 20%","Product Range:":"Simple Switcher Series","Packaging:":"Each","DC Resistance Max:":"0.05 ohm"}...
