SS26V Type Overview Applications The KEMET SS Coils, SS26V Type AC line filters are offered in a wide variety of sizes and specifications. * Consumer Electronics * Common mode choke Benefits * Wide variety of sizes and specifications * High inductance in a compact design * Pin pitch is identical to SS28V Type and SS24V Type, making design and replacement easier * Inductances up to 117 mH * Rated Currents up to 3 A * DC Resistances as low as 0.10 Part Number System SS 26 V- R 05 1170 Series Core Size (mm) Core Orientation Core Type Rated Current (A) Minimum Inductance (mH) SS 26 = 26.0 V- = Vertical Blank = Standard R = High permeability 0x = 0.x A (e.g., 05 = 0.5 A) xx = x.x A (e.g., 25 = 2.5 A) xxx0 = xxx mH (e.g., 1170 = 117 mH) 0xxx = xx mH (e.g., 0162 = 16.2 mH) 00xx = x.x mH (e.g., 0038 = 3.8 mH) One world. One KEMET (c) KEMET Electronics Corporation * P.O. Box 5928 * Greenville, SC 29606 * 864-963-6300 * www.kemet.com LF0030_SS26V * 3/30/2017 1 AC Line Filters - SS
