cathode end Mounting position: Any Weight: 0.093 gram 0.096(2.44) 0.083(2.13) 0.050(1.27) 0.030(0.76) 0.220(5.59) 0.200(5.08) 0.008(0.20) 0.203(0.10) Dimensions in inches and (millimeter) Maximum Rating and Electrical Characteristics Symbol SS22-G SS24-G SS26-G SS210-G Unit Max.Repetitive Peak Reverse Voltage V RRM 20 40 60 100 V Max. DC Blocking Voltage V DC 20 40 60 100 V Max. RMS Voltage V RMS 14 28 42 70 V Parameter Peak Surge Forward Current 8.3ms single half sine-wave superimposed on rate load ( JEDEC method ) I FSM 50 A Max. Average Forward Current Io 2.0 A Max. Instantaneous Forward Current at 2.0 A VF Max. DC Reverse Current at Rated DC Blocking Voltage Ta=25 C IR Ta=100 C Max. Thermal Resistance (Note 1) 0.70 0.50 0.5 20 R R JA JL V mA 10 75 17 Operating Junction temperature Tj -50 to +125 Storage Temperature T STG -65 to +150 Note 1: Thermal resistance from junction to ambient and junction to to lead P.C.B. Mounted on 0.2 x 0.2 copper pad areas "-G" suffix designates RoHS compliant Ve
